AMC - X86/X86i - 360W 6-Zone Digital H.O.M.E. System

The AMC X86i is a comprehensive 6-zone smart home audio system designed to deliver high-quality sound throughout multiple rooms. Each zone is powered by a 30W x 2 digital amplifier, providing robust audio performance across all areas. The system supports eight sources allowing users to access and control various audio inputs seamlessly.

Installation is streamlined, facilitating straightforward connectivity between the main unit and individual zones. The X86i employs a proprietary two-way digital data communication system, ensuring reliable interaction between the main unit and zone keypads. Each zone features independent volume and tone controls, enabling personalized audio settings to suit individual preferences.

Additional features include six 38kHz and six 56kHz IR outputs for versatile remote control capabilities, as well as optional doorbell and telephone mute functions via the PDM1 module. Designed with high-quality components, the AMC X86i offers a reliable and flexible solution for multi-room audio distribution, catering to both residential and commercial applications.

Total Zones ................................................................................................... 6 Zones
Zone 1-6 with Speaker Outputs ................................ ........................... 30W rms x 2
Sources. ........................................................................ 8 Local / 6 Remote Sources
Sensitivity. ........................................................................................................60mV
IR outputs frequencies ...................................................... .Six 38KHz and six 56KHz
IR output level ................................................................................................. 5V P·P
Phone input sensitivity ........................................................... .AC25V-AC100V 20Hz
Doorbell Input sensitivity. . ................................... ............................... AC/DC 3-12V
Dimensions(WxHxD)........................................ . ........................... .432x147x381mm
Net weight… ................................................................................................. 10.8Kgs
